Metal Identification

Reviewed by Andrew Oriss, Quality Coordinator, Verichek Technical Services.

To identify a metal, start with quick field checks: a magnet test, color and patina, weight, and a file or spark test. These can help identify the metal family, such as carbon steel, stainless steel, aluminum, or copper alloy. To identify the exact alloy grade, use Positive Material Identification (PMI) with a handheld XRF analyzer, a LIBS analyzer, or spark OES, which analyze the metal’s composition in seconds.

Many metals can look similar at first glance, but their properties can be very different. These differences affect how a metal welds, machines, and holds up in service. Misidentifying an alloy can lead to weak welds, flawed cuts, or a failed part. Below are the methods, from quick field checks to lab-grade spectrometry, and when each one is the right call.

Field Checks and Traditional TestsModern Metal Testing Methods
Quick Field Checks (Magnet, Weight, File, Spot Test)Optical Emission Spectrometry (OES)
Appearance TestX-Ray Fluorescence (XRF)
Spark TestX-Ray Diffraction (XRD)
Rockwell Hardness TestLaser-Induced Breakdown Spectroscopy (LIBS)
Brinell Hardness TestHow to Identify Metal Alloys On Site

Metal Identification: From Field Checks to Alloy Grade

Metal identification matters in manufacturing, recycling, construction, and plant maintenance. Knowing how to identify a metal saves time, helps make sure the right material is used for the job, and improves safety. Field checks and traditional tests tell you the metal family, while modern spectrometers tell you the alloy grade. Most jobs use both in that order.

What Are Some Quick Field Checks to Identify Metals?

These checks need nothing more than a magnet, a file, and a known reference piece. They can identify the metal family in a minute or two. None of them, though, will tell you the alloy grade.

Magnet Test

Hold a strong magnet to a clean spot. If it sticks firmly, the piece is most likely carbon steel, cast iron, or a ferritic or martensitic (400-series) stainless steel. If it doesn’t stick, the piece could be aluminum, copper, brass, bronze, lead, zinc, titanium, or an austenitic (300-series) stainless steel such as 304 or 316. A weak pull on stainless often means it was cold worked, not that it’s a different grade. Treat the magnet as a sorter, not an identifier: it can help separate ferrous from non-ferrous metals, but it can’t identify the exact alloy grade.

Scrap yards use the same test as a first step. See how they sort and grade scrap in our guide to scrap metal recycling.

Weight and Density

Compare the piece to a similar-sized piece of a known metal. Aluminum weighs about a third as much as steel. Copper and brass feel heavier than steel, and lead is heavier still but soft enough to scratch with a fingernail. Titanium sits between aluminum and steel: noticeably lighter than steel, with a gray appearance that can resemble stainless steel.

File and Scratch Test

Run a file across an edge. A file skates over hardened tool steel, cuts mild steel with steady pressure, and bites easily into aluminum, copper, and lead. Aluminum tends to load up (gum) the file. A fresh scratch also shows the true color under paint, plating, or oxide.

Chemical Spot Tests

Spot test kits use a drop of reagent to flag one element on a cleaned surface. The most common use in the field is separating 316 stainless from 304 with a molybdenum spot test, since the two look and behave identically to a magnet. Spot tests answer one question at a time and leave a small mark, so they have their limits and are not a substitute for an analyzer.

Appearance Test

Appearance alone usually isn’t enough to identify a metal, but it can help narrow down the metal family. Look at the metal’s color, surface condition, and any machining marks.

  • Red or orange: copper
  • Yellow or gold: brass or bronze
  • Silver or gray: aluminum, stainless steel, zinc, galvanized steel, nickel alloys, or titanium (these metals can’t be reliably distinguished from one another by appearance)
  • Red-brown rust: iron or carbon steel
  • Green or blue-green patina: copper, brass, or bronze
  • White, powdery oxide: aluminum, zinc, or galvanized coatings

Spark Test

A spark test is performed by pressing a piece of metal against a high-speed portable or stationary grinder to produce a stream of sparks. An experienced metal worker examines the length, color, and pattern of the sparks to help identify the metal.

As a rule of thumb, low-carbon steel throws long, bright yellow-white streams, and more carbon adds more forked bursts. Stainless steel throws shorter, darker orange streams with few bursts, and cast iron gives short, dull red streams. Aluminum, copper, and brass give off no sparks at all. The spark test can indicate carbon content and alloy family, but it can’t confirm a grade.

Reading a spark stream takes practice, so leave this test to experienced technicians and confirm any grade call with an analyzer.

Rockwell Hardness Test

A Rockwell hardness tester is needed to measure the depth of an indentation made by a diamond cone or tungsten carbide ball under a set load (ASTM E18). The test measures only one of the metal’s properties: its hardness. Soft metals will produce a deeper indentation, while hard metals will produce a shallower one.

Hardness, however, doesn’t identify a metal. Two different alloys can share a hardness, and one alloy can vary widely with heat treatment. Use it to confirm a part is in the right condition once you know what it’s made of.

Brinell Hardness Test

The Brinell hardness test is similar to the Rockwell test since both evaluate the impression left by an indenter. Unlike Rockwell, though, Brinell measures the area of impression. A 10 mm tungsten carbide ball is pressed into the metal surface under a 3,000 kgf load (for steel and cast iron; softer metals use lighter loads) to create an impression. The impressed area is then measured to determine a hardness number (ASTM E10). A large impressed area indicates softer metal, which means a lower hardness number. Because the impression is large, Brinell is well suited to rough or coarse-grained parts such as castings and forgings.

Comparing Traditional Metal Testing Methods

MagnetAppearanceSparkRockwellBrinell
Based onMagnetic attractionColor and surfaceSpark stream from a grinderDepth of an indentationArea of an indentation
Tells youFerrous or non-ferrousMetal familyCarbon level and metal familyHardnessHardness
EquipmentA magnetNoneGrinderRockwell testerBrinell tester
LimitationCan’t separate gradesDoes not always provide sufficient informationNeeds a trained technicianNeeds a prepared surfaceLarge impression; used for rough surfaces

Modern Metal Testing Methods: Positive Material Identification (PMI)

Modern metal testing reads the chemistry instead of the appearance. The standard approach is Positive Material Identification (PMI), done with X-ray fluorescence (XRF), laser-induced breakdown spectroscopy (LIBS), or optical emission spectrometry (OES).

PMI is the analysis of metallic alloy to determine its composition and identify its alloy grade by measuring the percentage of each element. This reading is what lets a QC team accept, reject, or quarantine material against a spec.

All three give results within seconds of testing. XRF and LIBS are non-destructive, while spark OES leaves a small burn mark on a ground spot. Some advantages of PMI analyzers include:

  • Confirming that materials meet the required specifications and standards
  • Determining whether materials or products were manufactured using the right combination of metallic elements (alloys)
  • Ensuring the right filler material was used in the materials or metals which have been welded
  • Checking whether the wrong elements or metals were used in the production of the alloy

Optical Emission Spectrometry (OES)

Optical Emission Spectrometry (OES), also called spark OES or arc/spark emission spectrometry, is fast and gives an exact quantitative breakdown of solid metals. OES, a form of atomic emission spectrometry, uses the intensity of light emitted at particular wavelengths to determine the elemental composition of a sample. A single element can produce many spectral lines, each with its own characteristic. Like fingerprints, these emission lines are unique to each element.

The analysis is given as a percentage breakdown. OES analysis is versatile and can be run on stationary, portable, or mobile spectrometers. Its key advantage is that spark OES measures carbon, along with phosphorus, sulfur, and boron. That makes it the method of choice when the grade depends on carbon, such as telling 304L from 304 stainless or checking carbon equivalent on steel for welding. It needs argon and a ground surface, and the spark leaves a small burn mark.

Optical emission spectrometry involves applying electrical energy in the form of a spark generated between an electrode and a metal sample. The vaporized atoms are then brought to a high energy state within a so-called “discharge plasma”.

X-Ray Fluorescence (XRF)

X-Ray Fluorescence (XRF) is a precise, fully non-destructive measure of the elemental composition of materials. XRF spectrometers excite a sample with high-energy X-rays, forcing the sample to emit characteristic X-rays that the spectrometer reads.

With a handheld XRF analyzer such as the Hitachi X-MET8000, common grades identify in a few seconds, while elements at part-per-million levels can take up to a few minutes. XRF is well suited to analyzing stainless steels, nickel and cobalt alloys, copper alloys, and titanium. It can’t measure carbon, and light elements such as magnesium, aluminum, and silicon are more difficult to detect. Paint, plating, and scale can also affect the accuracy of the results, so the test spot needs to be clean bare metal.

X-Ray Diffraction (XRD)

X-Ray Diffraction (XRD) identifies the crystal structure of a material, not its chemical composition. XRD can be used hand in hand with XRF: XRF tells you which elements are present, and XRD tells you how they are arranged, which adds context such as whether a steel is austenitic or ferritic or how much retained austenite is left after heat treatment.

The process identifies the crystalline phases present and compares them to a database of reference phases. Samples are usually ground to a powder or polished flat, so XRD is a lab method rather than a field test.

XRD helps evaluate minerals, polymers, corrosive products, and other unknown materials. This method can be useful for identifying and quantifying phases, as well as performing texture analysis.

Laser-Induced Breakdown Spectroscopy (LIBS)

Laser-induced breakdown spectroscopy (LIBS) is a form of atomic emission spectrometry, but it uses a highly energetic laser pulse to excite the sample. It leaves only a microscopic burn mark, so it’s treated as non-destructive for most work. Because it reads light alloys quickly, it’s popular in scrap metal analysis.

A handheld LIBS analyzer such as the Hitachi Vulcan fires a laser that creates a high-temperature plasma on the sample surface, and the light from the plasma shows the composition. The Vulcan identifies common alloy grades in about a second, carries a library of up to 1,500 grades (AISI, DIN, JIS, and GB), and covers aluminum, magnesium, titanium, cobalt, chromium, nickel, copper, stainless, tool, and low-alloy steels. It uses a laser instead of an X-ray tube, so there is no X-ray registration to manage; however, operators still need laser safety training.

Comparing Modern Metal Testing Methods

Spark OESHandheld XRFHandheld LIBSXRD
MeasuresElemental composition, including carbonElemental compositionElemental compositionCrystal structure (phases)
Reads carbonYesNoModel dependentNo
Best forCarbon steels, L-grade stainless, melt and weld chemistryStainless, nickel, cobalt, and copper alloys, titaniumAluminum and magnesium alloys, fast scrap sortingPhase and heat-treatment questions
Sample impactSmall burn mark; ground surfaceNoneMicroscopic burn markPrepared sample (lab)
Where it runsLab, mobile, or portableHandheld, in the fieldHandheld, in the fieldLab bench

Modern techniques like Positive Material Identification give you the alloy grade in seconds, where traditional metal testing methods can only provide general information on your samples. From handheld analyzers to bench-top lab OES and mobile OES, you can browse our inventory of metal analyzers. Our used metal analyzers are tested for quality before they ship. For a deeper side-by-side on accuracy, elements, and cost of ownership, see our XRF vs LIBS vs OES metal analysis guide.

If you’re not sure which metal analyzer is the best fit for your job, talk to a Verichek metal testing specialist for a recommendation. We also provide metal testing services and product support for businesses throughout North America. Contact us if you need spectrometer repair or professional PMI service.

When you make the case for an analyzer, weigh it against what one wrong part costs: scrapped or reworked assemblies, a line stopped while suspect material is quarantined, and an audit finding when the PMI record can’t be produced. Teams that test every day usually own an analyzer, while lower-volume programs often outsource to a service or lease or finance the instrument to spread the cost. Our buy, rent, or outsource guide compares the cost of each option.

How to Identify Metal Alloys On Site

On-site alloy identification is PMI done where the material is: on a receiving dock, in a plant, or on installed pipe and welds. The workflow below follows ASTM E1476, the standard guide for metals identification, grade verification, and sorting.

1. Sort First With Field Checks

Use the magnet and appearance checks to split ferrous from non-ferrous and set obvious mismatches aside. This keeps analyzer time for the parts that need it.

2. Prepare the Test Surface

Grind or sand a small spot to clean bare metal. Paint, plating, galvanizing, scale, and oxide all skew handheld readings, and spark OES needs a flat, ground surface to seal against the probe.

3. Read the Alloy With Handheld XRF or LIBS

Shoot the prepared spot and compare the chemistry against the grade library and the specification the part was ordered to. Handheld XRF is the usual choice for stainless, nickel alloys, and red metals. Handheld LIBS is faster on aluminum and magnesium alloys.

4. Step Up to Spark OES When Carbon Matters

Handheld XRF can’t read carbon. When the grade depends on it, such as L-grade stainless, carbon steel for sour service, or carbon equivalent for welding, use a mobile spark OES such as the PMI-Master Smart.

5. Verify the Analyzer and Record the Result

Check the analyzer against a certified reference standard at the start of each shift, and record each reading against the part, heat number, or weld it came from. Annual analyzer certification keeps the readings defensible in an audit.

Standards That Govern On-Site PMI

  • ASTM E1476: Standard Guide for Metals Identification, Grade Verification, and Sorting.
  • API RP 578: Guidelines for a Material Verification Program (MVP) for New and Existing Assets, used by refineries and petrochemical plants to decide what gets PMI tested and how.

Need alloy grades verified on site? Verichek technicians run PMI testing with handheld XRF and mobile spark OES at customer facilities across North America. Schedule a service visit.

Which Method Should I Use to Identify Different Types of Metals?

Use the method that best suits your testing needs.

  • To sort a mixed bin or a receiving lot into metal families, field checks and the spark test are enough.
  • To check heat treatment or condition, use a Rockwell or Brinell hardness test.
  • To identify an alloy grade, verify material against a specification, or settle a dispute, use PMI with handheld XRF or LIBS.
  • When carbon content matters, use Spark OES.

For on-site alloy verification or advanced metal identification needs, we offer PMI testing services. Talk to a Verichek metal testing specialist to learn more.

Metal Identification FAQs

Can a magnet tell you what metal something is?

No. A magnet is a sorter, not an identifier. If it sticks, the piece is most likely carbon steel, cast iron, or a 400-series stainless steel (nickel and cobalt are magnetic too). If it doesn’t stick, the piece could be aluminum, copper, brass, bronze, lead, zinc, titanium, or a 300-series stainless steel such as 304 or 316. To name the actual alloy, you need its chemistry, which is what a handheld XRF or LIBS analyzer reads.

What is the difference between 304 and 304L stainless steel?

Carbon. 304 allows up to 0.08% carbon, and 304L caps it at 0.03%, which improves weldability and corrosion resistance at the weld. The rest of the chemistry overlaps, so telling them apart takes an analyzer that reads carbon: spark OES or a carbon-capable LIBS analyzer. Handheld XRF can’t separate them.

Can handheld XRF identify carbon steel grades?

Not on its own. XRF can’t measure carbon, which is what separates most carbon steel grades. It can read the alloying and residual elements, such as chromium, molybdenum, nickel, and manganese, so it will catch a low-alloy steel mixed in with carbon steel. To confirm a carbon steel grade or carbon equivalent, use spark OES.

What is alloy identification testing?

Alloy identification testing, also called Positive Material Identification (PMI), measures the elements in a metal and matches the result to a grade, such as 316L stainless or 6061 aluminum.It’s done with handheld XRF, LIBS analyzers, or spark OES, usually without damaging the part. ASTM E1476 covers metals identification and grade verification, and API RP 578 sets out how refineries and plants run material verification programs.

What does API RP 578 require for PMI?

API RP 578 sets out a material verification program for alloy pressure-containing components in new and existing assets, mostly in refineries and petrochemical plants. It guides which components get PMI tested, how much of each lot to test, and how results are documented. The owner-user sets the program’s scope and the extent of testing.

How often does a handheld analyzer need certification?

Most programs certify handheld XRF and LIBS analyzers once a year and check them against a certified reference standard at the start of each shift or each day of testing. Your quality system or customer may set a tighter interval. Verichek offers LIBS & XRF Certification and Calibration Verification.

Need to know exactly what alloy you have? Talk to a Verichek metal testing specialist about handheld XRF and LIBS analyzers, analyzer certification, or on-site PMI testing.
